FB Sphere parameters and models from FlexBlockSystem
Our product line consists of four variants, differing in shape, mass, and dimensions, which directly impacts their application scope.
FB Sphere mats are available in four models: FB-60S, FB-100S, FB-150S, FB-240S
Key features include:
Length: 2746 mm (±5%)
Width: 1226 mm (±5%)
Height: 60 to 240 mm (model dependent)
Area: from 3.37 m²
Mass: 394 to 1200 kg
Concrete volume: 0.166 to 0.51 m³
Rope and lifting eye breaking load: 2000 to 5000 kgf
- Used for reinforcing slopes, embankments, and shorelines with light loads.
- Applied for soil erosion protection in areas with minor water flow.
- Ideal for landscaping, creating garden paths, and decorative landscape elements.
- Used for strengthening small riverbeds, canals, and drainage systems.
- Used to protect road and railway slopes from erosion.
- Effective for creating temporary access roads and platforms at construction sites.
- Used for protecting reservoir banks with moderate currents and wave loads.
- Applied for reinforcing dams, canals, and drainage structures.
- Suitable for creating temporary and permanent roads on weak soils.
- Used for strengthening banks of large rivers, sea and river ports, areas with high hydrodynamic loads.
- Used for protecting bridge foundations, hydraulic structures, and berths.
- Effective for reinforcing and stabilizing slopes with a high risk of landslides.
Click to view the image in detail, or download the organization's standard via the link below
For each mat type, reference geometric dimensions of concrete blocks are provided:
To receive consultation and select the optimal solution, please contact our specialists.и.
- Overall block dimensions (A×A): 300×300 mm
- Dimensions of the top and bottom block vertices
- Height of the top and bottom block
To receive consultation and select the optimal solution, please contact our specialists.и.
You can learn about our other pyramid-shaped model by clicking the button on the right
