FB Pyramid parameters and models from FlexBlockSystem
Our product range consists of five variants, which have different shapes, weights and dimensions, which in turn directly affects the scope of their application
"FB Pyramid" mats are available in five models: FB-60P, FB-100P, FB-105PA, FB-150P, FB-240P
Key features include:
Length: 2746 mm (±5%)
Width: 1226 mm (±5%)
Height: 60 to 240 mm (model dependent)
Area: from 3.37 m²
Mass: 406 to 1253 kg
Concrete volume: 0.171 to 0.53 m³
Rope and lifting eye breaking load: 2000 to 5000 kgf
- Used for erosion control on slopes, embankments, and light-load fills.
- Used for bank stabilization of small water bodies, canals, and low-water drainage systems.
- Ideal for landscaping, creating garden paths, pedestrian areas, and decorative landscape elements
- Used for reinforcing slopes of road and railway embankments, as well as canals with moderate water flow.
- Applied for erosion and landslide protection in areas with high humidity.
- Effective for creating temporary access roads and platforms at construction sites.
- Designed for strengthening small riverbeds, drainage channels, and storm drains.
- Used for slope and embankment protection in areas with variable hydrodynamic loads.
- Applied for soil stabilization in areas prone to localized landslides.
- Used for protecting reservoir, river, and canal banks with moderate to strong currents.
- Used for reinforcing dams, hydraulic structures, bridge piers, and drainage systems.
- Suitable for creating temporary and permanent roads on weak and waterlogged soils.
- Used for reinforcing banks of major rivers, sea and river ports, and areas with high wave and hydrodynamic loads.
- Applied to protect foundations of bridges, piers, hydraulic structures, and coastal defenses.
- Effective for stabilizing slopes and embankments with a high risk of erosion.
Кликните, чтобы более детально рассмотреть изображение, либо скачайте стандарт организации по ссылке ниже
For each mat type, reference geometric dimensions of concrete blocks are provided:
For consultation and optimal solution selection, please contact our specialists.
- Overall block dimensions (A×A): 300×300 mm
- Dimensions of the top and bottom block vertices
- Height of the top and bottom block
For consultation and optimal solution selection, please contact our specialists.
You can learn about our other spherical model by clicking the button on the right
